30KG 40PA H13 HEPA Filter , 370w Fan Filter Unit FFU For Clean Room

    Buy cheap 30KG 40PA H13 HEPA Filter , 370w Fan Filter Unit FFU For Clean Room from wholesalers

    Buy cheap 30KG 40PA H13 HEPA Filter , 370w Fan Filter Unit FFU For Clean Room from wholesalers
    • Buy cheap 30KG 40PA H13 HEPA Filter , 370w Fan Filter Unit FFU For Clean Room from wholesalers

    30KG 40PA H13 HEPA Filter , 370w Fan Filter Unit FFU For Clean Room

    Ask Lasest Price
    Brand Name : anlaitech
    Model Number : AL-FFU
    Certification : CE , FAT
    Payment Terms : L/C, T/T, Western Union
    Delivery Time : 12WORKING DAYS.
    • Product Details
    • Company Profile

    30KG 40PA H13 HEPA Filter , 370w Fan Filter Unit FFU For Clean Room

    H13 HEPA Filter Fan filter Unit ffu for Clean room


    The FFU fan filter unit suitable for cleanrooms with turbulent air flow and especially designed for larger clean room areas. A cleanliness class 5.0 to 8.0 according DIN EN ISO 14644-1 can be achieved with the selection of the filter coverage percentage, volume-flow and variable filter-classes.

    The FFU RETURN AIR is available with a alternating current motor or a EC-Motor.


    FFU Feature:


    The following additional components at the air-inlet side are available:

    • Prefilter for coarse particle separation
    • AMC-Filter for the filtration of gaseous contaminations
    • Return-air covers for prefilter and AMC filter
    • Cover return-air duct

    If necessary filter cell class H13 to U17 can be used.


    Technical Data:


    ModelAL-FFU2*4
    Size(W*L*H)mm1175*575*350mm

    Weight

    30KGS
    Frequency

    50 Hz / 60 Hz (110V/120V /220V/230V/240V)

    Rated current

    between 1.8 A and 1.6 A

    Rated capacity

    370w
    Number of revolutions min.:300 1/min | max.: 1,304 1/min
    Flow velocity0.45 m/s adjustable
    External pressure differ40PA

    Air volume flow

    2,333 m³/h
    Power consumption150W
    Sound power level pressure side:

    63 dB (A)

    Clean room sound pressure level50 % occupancy: 66 dB (A)
